WM210V Benchtop lathe

Product Introduction：

Miling MachinelMetal LathelHigh Precision Spindle:Features a 21mm spindle bore and MT3 taperfor precise turning and threading.

Versatile Turning Capacity:With a 210mm turning diameter and 360mm distance between centers

handles a variety of projects.

Powerful Motor:Equipped with a robust 600W motor for efficient operation in woodworking andmetalworking.

Adjustable Speed Range:Offers a high and low speed range of 50-2500 RPM for diverse turningrequirements.

Compact and Portable Design:At 70kg and with a packing size of840x390x470, this mini lathe iseasy to move and store.

specifications：

	WM210*400mm	WM210*600mm	WM210*800mm	WM210*1000mm
Swing Over Bed	210mm	210mm	210mm	210mm
Swing Over Cross Slide	110mm	110mm	110mm	110mm
Distance Between Centers	400mm	600mm	800mm	1000mm
Width Of Bed	100mm	100mm	100mm	100mm
Spindle Bore	38mm	38mm	38mm	38mm
Spindle Taper	MT3	MT3	MT3	MT3
Number Of Spindle Speed	Varible	Varible	Varible	38mm
Range Of Spindle Speed	50-2500 r.p.m	50-2500 r.p.m	50-2500 r.p.m	38mm
Number Of Metric Threads	14	14	14	14
Range Of Metric Threads	0.5-3mm	0.5-3mm	0.5-3mm	0.5-3mm
Number Of Imperial Threads	10	10	10	10
Range Of Imperial Threads	10-44 T.P.I	10-44 T.P.I	10-44 T.P.I	10-44 T.P.I
Tool Post Type	4	4	4	4
Maximum Compoud Slide Travel	55mm	55mm	55mm	55mm
Maximum Carriage Slide Travel	75mm	75mm	75mm	75mm
Maximum Carriage Travel	300mm	520	620	720
Tailstock Spindle Travel	60mm	60mm	60mm	60mm
Taper In Tailstock Spindle	MT2
Main Motor	900W/220V/1PH/50HZ
Packing size	910/480/450mm	1110/480/450mm	1310/480/450mm	1510/480/450mm
